Stainless Steel TC End Elbow

Name: Stainless Steel TC End Elbow
Brand: STELLINOX GLOBAL PRIVATE LIMITED
Price: 200 INR
Availability: InStock

Price 200 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

Stainless Steel TC End Elbow Specification

Flexibility
Rigid

Tolerance
0.1 mm

Yield Strength
205 MPa (SS304)

Sealing Type
Gasket Required (Silicone/EPDM/PTFE)

Connection Type
Tri-Clamp Quick Connect

Bend Radius
1.5D

Tensile Strength
520 MPa (SS304)

Diameter
Varies (19 mm - 102 mm)

Thread Type
Not Applicable (TC End)

Temperature Range
-20C to 200C

Product Type
TC End Elbow

Material
Stainless Steel

Connection
Tri-Clamp (TC) End

Shape
Elbow (Curved)

Standard
DIN, SMS, 3A, ISO

Surface Treatment
Polished

Outer Diameter
19 mm - 102 mm

Section Shape
Round

Length
Varies by specification (typically 50 mm - 300 mm)

Thickness
1.2 mm - 3 mm

Color
Silver

Usage
Sanitary / Food / Pharmaceutical / Dairy / Beverage

Rated Pressure
10 bar - 16 bar

Application
Process Piping, Fluid Conveyance

Material Grade
SS304 / SS316

Finish Type
Mirror / Electro Polished

Weight
Varies with size and thickness

Elbow Angle
90 (available in 45 on request)

Media Compatibility
Suitable for CIP/SIP systems & food-grade media

Marking
Size, grade and manufacturer marking on request

Cleaning
Easy to clean, supports automated cleaning

End Type
Tri-Clamp (TC) ferrule ends both sides

Leak Proof
Yes, with appropriate gasket

Corrosion Resistance
Excellent

Hygienic Standard
cGMP compliant, EHEDG certified design available

Stainless Steel TC End Elbow Trade Information

Minimum Order Quantity
10 Pieces

Supply Ability
500 Pieces Per Month

Delivery Time
3 Days

About Stainless Steel TC End Elbow

Buy the brilliant Stainless Steel TC End Elbow, superbly engineered for incomparable performance across sanitary, food, pharmaceutical, and beverage sectors. Explore its robust Tri-Clamp ends, available in both mirror and electro-polished finishes. With excellent corrosion resistance and leak-proof sealing, this cGMP-compliant elbow easily supports CIP/SIP applications. Access EHEDG-certified designs for optimal hygiene. Designed for effortless cleaning and featuring accurate markings on request, this elbow is an exceptional choice for process piping, fluid conveyance, and high-standard applications. Bulk orders, export, and wholesale options available across India.

Versatile Applications & Exceptional Features

The Stainless Steel TC End Elbow is a superb solution for process piping and fluid conveyance in the food, pharmaceutical, dairy, and beverage industries. Suitable for sanitary environments, it boasts easy-to-clean mirror or electro-polished surfaces, ensuring maximum hygiene. Its compatibility with CIP/SIP systems and robust corrosion resistance make it ideal for critical applications. The rigid, leak-proof design ensures reliable operation in high-pressure and temperature conditions, perfectly suiting diverse, demanding processing needs.

Swift Delivery & Certified Quality

Once the outlay is finalized, your Stainless Steel TC End Elbow will be expediently handed over to our dispatch team. Shipment is completed in a timely manner, typically within days, ensuring your operations remain on schedule. Each elbow is manufactured under stringent certifications such as cGMP and optional EHEDG standards, meeting DIN, SMS, 3A, and ISO requirements. Widely distributed throughout India, our main domestic market benefits from our commitment to reliability and outstanding service.

FAQ's of Stainless Steel TC End Elbow:

Q: How is the Stainless Steel TC End Elbow cleaned or maintained?

A: The elbow is designed for easy cleaning and supports automated CIP/SIP processes, making it ideal for sanitary and critical hygienic applications.

Q: What makes the TC End Elbow suitable for food and pharmaceutical uses?

A: Its hygienic, mirror/electro-polished finish, cGMP compliance, EHEDG-certified design, and resistance to corrosion ensure suitability for food, beverage, and pharmaceutical environments.

Q: Where can the Stainless Steel TC End Elbow be applied effectively?

A: This elbow is optimal for process piping and fluid conveyance in sanitary, food, pharmaceutical, dairy, and beverage sectors.

Q: What connection type is featured on the TC End Elbow?

A: Both ends feature Tri-Clamp (TC) ferrule ends for quick-connect, leak-proof, and hygienic installation.

Q: When can I expect shipment and delivery of my order?

A: Once your order and outlay are confirmed, the product is handed over for shipment, typically dispatched within a few working days depending on location and stock availability.
